COMPACT Specifications
The COMPACT is a trailer sized solar-hybrid power system series is designed to provide consistent renewable energy with ease up to 22.5kVA. Our units are each fitted with folding solar.
The power systems provides multiple layers of redundancy and can operate with extremely long maintenance intervals. In most applications, the COMPACT will reduce your daily reliance on diesel generators by between 80 and 100%.
FPS20-10 Specifications
Output Type Single Phase
Maximum continuous output 22kVA
Solar array size 10kWh
Backup generator output 14.4kVA
Inverter peak output 18kW
Maximum battery capacity 50kWh
Fuel capacity 200L
Weight 5.5 Tonne
Length 6.10m
Length 6.10m
Weight 5.6 Tonne
Width packed 2.44m
Height packed 3.15m
